| SIZE |
100mm(W)x80mm(L)x15mm(H) Small Size |
| CPU |
S3C2410A(ARM920T) 266MHz |
| MEMORY |
2MB NOR , 64MB NAND, 64MB(32MB x 2) SDRAM |
| I/O |
Power(2Pin), Serial(3Pin), JTAG(7Pin),External I/O(160 Pin) |
| UART |
RS-232 1ch |
| ADC |
Resolution 10bit, 1ch.(0~3.3V) |
| TOUCH |
Resistive Overlay Type |
| USB |
Device(B Type) 1ch. Support |
| JTAG |
14Pin |
| Data Line
|
RGB (24Bit Data Line, 2ch.)
CPU (16Bit Data Line, 2ch.)
|
| Function Key
|
(User Customized)
- Key1 : Still Image Previous
- Key2 : Still Image Next
- Key3 : Moving Image Show
- Key4 : Auto Slide & Full Show Mode
- Key5 : Reset
|
| Disk |
SD Card Support
|
| Appliction |
LCD Demo Display Kit, Pattern Generator, LCD Engineering Tester
|
