| SIZE |
235mm(W)x200mm(H)x135mm(D) Small Size |
| Weight |
2.01 Kg |
| Output frequency |
2MB NOR , 64MB NAND, 64MB(32MB x 2) SDRAM |
| Monitor |
480x272 Color TFT (WQVGA 4.3”) |
| UART |
RS-232 1ch |
| Memory |
SDRAM 64Mbyte, NAND Flash 64Mbyte, 1Gbyte SD CARD(External Memory) |
| Output conn. |
62pin connector (HDSUB female), 25pin connector (DSUB female) |
| Power |
9.0V --- 3.0A |
| main function |
- 2048 X 2048 High display resolution support
- Test pattern image from PC
- EPD timing generation
- PC interface using RS-232 & USB
- JIG control interface support
- save test module infomation
- save test sequence
- EPD driving voltage/current control / monitor
- supply test sequence editing program
- external control (RS-232)
- other signal extention board |
| Operation env. |
pneumatic test zig : Optional (1ch, 2ch) |
| Appliction |
EPD Demo Display Kit, Pattern Generator, EPD Engineering Tester |
